The growth rate of an SiO2 film on various metal–oxide (M–O) underlayers by plasma-enhanced atomic layer deposition (ALD) using tris(dimethylamino)silane precursor and O2 plasma gas is systematically investigated, and the effect of the difference in the electronegativity of the M–O underlayer on the ALD-SiO2 growth mechanism is also discussed. All data for the ALD-SiO2 film thickness on HfO2, TiO2, Al2O3, and SiO2 underlayers satisfied a linear relationship as a function of the ALD cycle. The growth per cycle (GPC) value of the ALD-SiO2 film increased in the following order: SiO2 (0.043 nm/cycle) < Al2O3 (0.14) < TiO2 (0.17) < HfO2 (0.22). On the other hand, the negative charge concentration of oxygen atoms in the M–O underlayer becomes higher in the following order: Si–O (1.76 eV) < Al–O (2.03) < Ti–O (2.18) < Hf–O (2.27) due to the electronegativity difference between the Si, Al, Ti, Hf, and O elements of the M–O underlayer. A correlation between the GPC of the ALD-SiO2 film and the difference in the electronegativity of the M–O underlayer was also determined.
Skip Nav Destination
Correlation between SiO2 growth rate and difference in electronegativity of metal–oxide underlayers for plasma enhanced atomic layer deposition using tris(dimethylamino)silane precursor
,
,
,
,
,
,
Article navigation
Research Article|
April 10 2020
Correlation between SiO2 growth rate and difference in electronegativity of metal–oxide underlayers for plasma enhanced atomic layer deposition using tris(dimethylamino)silane precursor
Available to Purchase
Special Collection:
Special Topic Collection on Atomic Layer Deposition (ALD)
Erika Maeda;
Erika Maeda
a)
1
Shibaura Institute of Technology
, 3-7-5 Toyosu, Koto-ku, Tokyo 135-8548, Japan
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Toshihide Nabatame
;
Toshihide Nabatame
b)
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Masafumi Hirose;
Masafumi Hirose
1
Shibaura Institute of Technology
, 3-7-5 Toyosu, Koto-ku, Tokyo 135-8548, Japan
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Mari Inoue;
Mari Inoue
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Akihiko Ohi
;
Akihiko Ohi
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Naoki Ikeda
;
Naoki Ikeda
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
Search for other works by this author on:
Hajime Kiyono
Hajime Kiyono
1
Shibaura Institute of Technology
, 3-7-5 Toyosu, Koto-ku, Tokyo 135-8548, Japan
Search for other works by this author on:
Erika Maeda
1,2,a)
Toshihide Nabatame
2,b)
Masafumi Hirose
1,2
Mari Inoue
2
Akihiko Ohi
2
Naoki Ikeda
2
Hajime Kiyono
1
1
Shibaura Institute of Technology
, 3-7-5 Toyosu, Koto-ku, Tokyo 135-8548, Japan
2
National Institute for Materials Science (NIMS)
, 1-1 Namiki, Tsukuba, Ibaraki 305-0044, Japan
a)
Electronic addresses: [email protected] and [email protected]
b)
Electronic mail: [email protected]
Note: This paper is part of the 2020 Special Topic Collection on Atomic Layer Deposition (ALD).
J. Vac. Sci. Technol. A 38, 032409 (2020)
Article history
Received:
February 04 2020
Accepted:
March 26 2020
Citation
Erika Maeda, Toshihide Nabatame, Masafumi Hirose, Mari Inoue, Akihiko Ohi, Naoki Ikeda, Hajime Kiyono; Correlation between SiO2 growth rate and difference in electronegativity of metal–oxide underlayers for plasma enhanced atomic layer deposition using tris(dimethylamino)silane precursor. J. Vac. Sci. Technol. A 1 May 2020; 38 (3): 032409. https://doi.org/10.1116/6.0000078
