High-quality Pt thin films are prepared by atomic layer deposition (ALD) using metal-organic precursors dimethyl-(N,N-dimethyl-3-butene-1-amine-N) platinum (C8H19NPt) and with diluted molecular oxygen (O2) as a reactant. The films are grown at a relatively low temperature of 225 °C on a thermally grown SiO2 substrate, and the process shows all the necessary qualities of an ideal ALD such as self-limiting growth characteristics and a well-defined ALD temperature window between 200 and 250 °C. Noticeably, the current ALD-Pt process shows a very high growth per cycle of 0.167 nm without an incubation period at 225 °C, and perfect conformality is obtained at a dual trench structure (top and bottom width: 40 and 15 nm) with an aspect ratio of around 6.3. The resistivity of the ALD-Pt film at ∼39 nm in thickness deposited at 225 °C is almost the same (∼10.8 μΩ cm) as its bulk resistivity (10.6 μΩ cm), and it is as low as ∼12 μΩ cm at 25 nm in thickness. Comprehensive analyses using x-ray photoelectron spectroscopy, x-ray diffractometry, transmission electron microscopy (TEM), and x-ray reflectance indicate that the extremely low resistivity of ALD-Pt is due to the formation of highly pure and polycrystalline films with high density (∼21.04 g/cm3) and large grain size (∼48 nm for 25 nm thick film). For comparison, ALD-Ru is deposited at the same equipment and deposition temperature, 225 °C, using (ethylbenzene)(1,3-butadiene)Ru(0) (C12H16Ru) and diluted O2 as the reactant. The higher resistivity of ∼20 μΩ cm at a similar thickness (∼23.5 nm) with ALD-Pt is obtained, which is much higher than its bulk value (7.6 μΩ cm). TEM analysis suggests that the formation of relatively smaller-sized grains of ALD-Ru is the main reason for it.
Skip Nav Destination
,
,
,
,
,
,
,
Article navigation
Research Article|
March 19 2020
Atomic layer deposition of high-quality Pt thin film as an alternative interconnect replacing Cu Available to Purchase
Special Collection:
Special Topic Collection on Atomic Layer Deposition (ALD)
Seung-Min Han;
Seung-Min Han
a)
1
School of Materials Science and Engineering, Yeungnam University
, 214-1, Dae-dong, Gyeongsan-City 712-749, South Korea
Search for other works by this author on:
Dip K. Nandi;
Dip K. Nandi
a)
1
School of Materials Science and Engineering, Yeungnam University
, 214-1, Dae-dong, Gyeongsan-City 712-749, South Korea
Search for other works by this author on:
Yong-Hwan Joo;
Yong-Hwan Joo
1
School of Materials Science and Engineering, Yeungnam University
, 214-1, Dae-dong, Gyeongsan-City 712-749, South Korea
Search for other works by this author on:
Toshiyuki Shigetomi;
Toshiyuki Shigetomi
2
Tanaka Precious Metals
, 22, Wadai, Tsukuba Ibaraki 300-4247, Japan
Search for other works by this author on:
Kazuharu Suzuki;
Kazuharu Suzuki
2
Tanaka Precious Metals
, 22, Wadai, Tsukuba Ibaraki 300-4247, Japan
Search for other works by this author on:
Shunichi Nabeya;
Shunichi Nabeya
2
Tanaka Precious Metals
, 22, Wadai, Tsukuba Ibaraki 300-4247, Japan
Search for other works by this author on:
Ryosuke Harada;
Ryosuke Harada
2
Tanaka Precious Metals
, 22, Wadai, Tsukuba Ibaraki 300-4247, Japan
Search for other works by this author on:
Soo-Hyun Kim
Soo-Hyun Kim
b)
1
School of Materials Science and Engineering, Yeungnam University
, 214-1, Dae-dong, Gyeongsan-City 712-749, South Korea
Search for other works by this author on:
Seung-Min Han
1,a)
Dip K. Nandi
1,a)
Yong-Hwan Joo
1
Toshiyuki Shigetomi
2
Kazuharu Suzuki
2
Shunichi Nabeya
2
Ryosuke Harada
2
Soo-Hyun Kim
1,b)
1
School of Materials Science and Engineering, Yeungnam University
, 214-1, Dae-dong, Gyeongsan-City 712-749, South Korea
2
Tanaka Precious Metals
, 22, Wadai, Tsukuba Ibaraki 300-4247, Japan
a)
Contributions: S.-M.H. and D.K.N. contributed equally to this work.
b)
Electronic mail: [email protected]
Note: This paper is part of the 2020 Special Topic Collection on Atomic Layer Deposition (ALD).
J. Vac. Sci. Technol. A 38, 032404 (2020)
Article history
Received:
November 02 2019
Accepted:
March 04 2020
Citation
Seung-Min Han, Dip K. Nandi, Yong-Hwan Joo, Toshiyuki Shigetomi, Kazuharu Suzuki, Shunichi Nabeya, Ryosuke Harada, Soo-Hyun Kim; Atomic layer deposition of high-quality Pt thin film as an alternative interconnect replacing Cu. J. Vac. Sci. Technol. A 1 May 2020; 38 (3): 032404. https://doi.org/10.1116/1.5134696
