Time-resolved ion energy measurements using a retarding potential analyzer for electric propulsion applications Available to Purchase

To completely characterize the evolving state of a plasma, diagnostic tools that enable measurements of the time-resolved behavior are required. In this study, a gridded ion source with superimposed oscillations was utilized to verify the functionality of a high-speed retarding potential analyzer (HSRPA), at frequencies equivalent to the low frequency oscillations occurring in Hall effect thrusters (HETs). The verification of this device provides an effective alternative to existing diagnostics for measuring time-resolved ion energies. Retarding potential analyzers (RPAs) have established themselves as a fundamental diagnostic in the field of electric propulsion (EP), enabling the measurement of ion energy distributions within the plumes of EP thrusters. The work presented here has demonstrated the capability of a standard RPA in conjunction with high-speed circuitry and data fusion techniques to produce time-resolved ion energy distribution functions (IEDFs) at higher frequencies and beam potentials than have previously been investigated. Tested frequencies ranged between 20 and 80 kHz with 10 V peak-to peak oscillations at a mean beam potential of 570 V. In addition, measurements were conducted with several waveforms, functioning as the superimposed oscillation, including a sine wave, triangle wave, and noisy sine wave. Data from the HSRPA were successfully reconstructed into time series utilizing two data fusion techniques: the empirical transfer function method and shadow manifold interpolation. Time-resolved IEDFs were produced at all frequency set points and waveforms. This investigation has demonstrated the HSRPA effectiveness at producing time-resolved measurements under conditions similar to those occurring in HETs.
