High-directivity and compact microstrip coupler for RF power applications Available to Purchase

A microstrip coupler was designed, fabricated, and tested to monitor the power of the 500 MHz kW-level amplifier modules currently installed in an 80-kW solid-state transmitter. The proposed coupler consists of multi-section coupled lines and employs a reverse-coupling scheme, achieving a very compact structure. The dual-side configuration with good termination enables the coupler to have high directivity and wide bandwidth without using any lump components for better temperature stability. Under a low-power test, the measured coupling is 37.69 dB with high directivity from 82 to 700 MHz. The coupling is almost independent of the power at 499.65 MHz, while the directivity slightly decreases to 33.85 dB at the input power of 1 kW. The maximal insertion loss of 0.08 dB was observed at 1-kW input power. The proposed directional coupler suits many high-power applications, especially in low-frequency regimes.
