Pendulum thrust stands are used to measure the thrust of electric propulsion systems for spacecraft. A thruster is mounted on a pendulum and operated, and the pendulum displacement due to thrust is measured. In this type of measurement, the pendulum is also affected by nonlinear tensions due to wiring and piping that deteriorate the accuracy of the measurement. This influence cannot be ignored in high power electric propulsion systems because complicated piping and thick wirings are required. Therefore, to reduce the influence of tension due to wires and tubes, we developed an inverted pendulum-type thrust stand with pipes and wirings as springs. In this paper, we first derive the design guidelines for spring-shaped wires; the necessary conditions for sensitivity, responsivity, spring shape, and electric wire were formulated. Next, a thrust stand was designed and fabricated based on these guidelines, and the performance of the stand was evaluated through calibration and thrust measurements using a 1 kW-class magneto-plasma-dynamics thruster. The sensitivity of the thrust stand was 17 mN/V, the normalized standard deviation of the variation of the measured values owing to the structure of the thrust stand was 1.8 × 10−3, and the thermal drift during the long-time operation was ∼4.5 × 10−3 mN/s.

1.
Y.
Sudo
,
R.
Tsukizaki
,
H.
Kuninaka
, and
Y.
Yamagiwa
, “
Development thrust measuring device using a CFRP as a measure of thermal drift
,” in
Space Transport Symposium
,
2015
.
2.
A. D.
Kodys
,
R.
Murray
,
L.
Cassady
, and
E. Y.
Choueiri
, “
An inverted-pendulum thrust stand for high-power electric thrusters
,” in
AIAA/ASME/SAE/ASEE 42nd Joint Propulsion Conference, 9 July 2006, Sacramento, CA
,
(AIAA
,
2006
) pp.
5008
5021
.
3.
K. A.
Polzina
,
T. E.
Markusic
,
B. J.
Stanojev
,
A.
DeHoyos
, and
B.
Spaun
,
Rev. Sci. Instrum.
77
,
105108
(
2006
).
4.
N.
Nagao
,
S.
Yokota
,
K.
Komurasaki
, and
Y.
Arakawa
, “
Development of a two-dimensional dual pendulum thrust stand for Hall thrusters
,”
Rev. Sci. Instrum.
78
,
115108
(
2007
).
5.
S.
Orieux
,
C.
Rossi
, and
D.
Estève
, “
Thrust stand for ground tests of solid propellant microthrusters
,”
Rev. Sci. Instrum.
73
,
2694
(
2002
).
6.
S.
Rocca
, “
ONERA micronewton thrust balance: Analytical modelling and parametric analysis
,”
Aerosp. Sci. Technol.
15
,
148
(
2011
).
7.
K. G.
Xu
and
M. L. R.
Walker
, “
High-power, null-type, inverted pendulum thrust stand
,”
Rev. Sci. Instrum.
80
,
055103
(
2009
).
8.
J. E.
Polk
 et al, “
Recommended practice for thrust measurement in electric propulsion testing
,”
J. Propul. Power
33
,
1
(
2017
).
9.
A.
Neumann
,
C.
Volkmar
,
C.
Geile
, and
K.
Hannemann
, “
Mitigation of detrimental electric thruster force measurement effects
,”
presented at the 35th International Electric Propulsion Conference
(
2017
), IEPC-
2017
162
.
