Dye-sensitized photocatalysts with molecular dyes and widegap semiconductors have attracted attention because of their design flexibility, for example, tunable light absorption for visible-light water splitting. Although organic dyes are promising candidates as metal-free photosensitizers in dye-sensitized photocatalysts, their efficiency in H2 production has far been unsatisfactory compared to that of metal-complex photosensitizers, such as Ru(II) tris-diimine-type complexes. Here, we demonstrate the substantial improvement of carbazole–thiophene-based dyes used for dye-sensitized photocatalysts through systematic molecular design of the number of thiophene rings, substituents in the thiophene moiety, and the anchoring group. The optimized carbazole–thiophene dye-sensitized layered niobate exhibited a quantum efficiency of 0.3% at 460 nm for H2 evolution using a redox-reversible I− electron donor, which is six-times higher than that of the best coumarin-based metal-free dye reported to date. The dye-sensitized photocatalyst also facilitated overall water splitting when combined with a WO3-based O2-evolving photocatalyst and an I3−/I− redox shuttle mediator. The present metal-free dye provided a high dye-based turnover frequency for water splitting, comparable to that of the state-of-the-art Ru(II) tris-diimine-type photosensitizer, by simple adsorption onto a layered niobate. Thus, this study highlights the potential of metal-free organic dyes with appropriate molecular designs for the development of efficient water splitting.
Skip Nav Destination
,
,
,
,
,
,
,
Article navigation
28 January 2024
Research Article|
January 31 2024
Metal-free carbazole–thiophene photosensitizers designed for a dye-sensitized H2-evolving photocatalyst in Z-scheme water splitting Available to Purchase
Special Collection:
The Physical Chemistry of Solar Fuels Catalysis
Akinobu Nakada
;
Akinobu Nakada
(Data curation, Formal analysis, Investigation, Visualization, Writing – original draft)
1
Department of Energy and Hydrocarbon Chemistry, Graduate School of Engineering, Kyoto University
, Nishikyo-ku, Kyoto 615-8510, Japan
2
PRESTO, Japan Science and Technology Agency (JST)
, Kawaguchi, Saitama 332-0012, Japan
Search for other works by this author on:
Takayuki Yokota;
Takayuki Yokota
(Data curation, Formal analysis, Investigation)
1
Department of Energy and Hydrocarbon Chemistry, Graduate School of Engineering, Kyoto University
, Nishikyo-ku, Kyoto 615-8510, Japan
Search for other works by this author on:
Morihiko Ogura
;
Morihiko Ogura
(Data curation)
3
Catalysis Research Center and Graduate School of Life Science, Hokkaido University
, Kita-ku, Sapporo 001-0021, Japan
Search for other works by this author on:
Ninghui Chang
;
Ninghui Chang
(Data curation)
3
Catalysis Research Center and Graduate School of Life Science, Hokkaido University
, Kita-ku, Sapporo 001-0021, Japan
Search for other works by this author on:
Osamu Tomita;
Osamu Tomita
(Investigation, Writing – review & editing)
1
Department of Energy and Hydrocarbon Chemistry, Graduate School of Engineering, Kyoto University
, Nishikyo-ku, Kyoto 615-8510, Japan
Search for other works by this author on:
Akinori Saeki
;
Akinori Saeki
(Data curation, Writing – review & editing)
4
Department of Applied Chemistry, Graduate School of Engineering, Osaka University
, 2-1 Yamadaoka, Suita, Osaka 565-0871, Japan
Search for other works by this author on:
Masamichi Ogasawara
;
Masamichi Ogasawara
(Data curation, Writing – review & editing)
5
Department of Natural Science, Graduate School of Science and Technology, Tokushima University
, Tokushima 770-8506, Japan
Search for other works by this author on:
Ryu Abe
Ryu Abe
a)
(Conceptualization, Funding acquisition, Project administration, Supervision, Writing – review & editing)
1
Department of Energy and Hydrocarbon Chemistry, Graduate School of Engineering, Kyoto University
, Nishikyo-ku, Kyoto 615-8510, Japan
a)Author to whom correspondence should be addressed: [email protected]
Search for other works by this author on:
Akinobu Nakada
1,2
Takayuki Yokota
1
Morihiko Ogura
3
Ninghui Chang
3
Osamu Tomita
1
Akinori Saeki
4
Masamichi Ogasawara
5
Ryu Abe
1,a)
1
Department of Energy and Hydrocarbon Chemistry, Graduate School of Engineering, Kyoto University
, Nishikyo-ku, Kyoto 615-8510, Japan
2
PRESTO, Japan Science and Technology Agency (JST)
, Kawaguchi, Saitama 332-0012, Japan
3
Catalysis Research Center and Graduate School of Life Science, Hokkaido University
, Kita-ku, Sapporo 001-0021, Japan
4
Department of Applied Chemistry, Graduate School of Engineering, Osaka University
, 2-1 Yamadaoka, Suita, Osaka 565-0871, Japan
5
Department of Natural Science, Graduate School of Science and Technology, Tokushima University
, Tokushima 770-8506, Japan
a)Author to whom correspondence should be addressed: [email protected]
J. Chem. Phys. 160, 044710 (2024)
Article history
Received:
September 30 2023
Accepted:
January 09 2024
Citation
Akinobu Nakada, Takayuki Yokota, Morihiko Ogura, Ninghui Chang, Osamu Tomita, Akinori Saeki, Masamichi Ogasawara, Ryu Abe; Metal-free carbazole–thiophene photosensitizers designed for a dye-sensitized H2-evolving photocatalyst in Z-scheme water splitting. J. Chem. Phys. 28 January 2024; 160 (4): 044710. https://doi.org/10.1063/5.0179225
