In this study, we develop a new approach for stabilization of metallic phases of monolayer MoS2 through the formation of lateral heterostructures composed of semiconducting/metallic MoS2. The structure of metallic (a mixture of T and T′) and semiconducting (2H) phases was unambiguously characterized by Raman spectroscopy, x-ray photoelectron spectroscopy, photoluminescence imaging, and transmission electron microscope observations. The amount of NaCl, reaction temperature, reaction time, and locations of substrates are essential for controlling the percentage of metallic/semiconducting phases in lateral heterostructures; loading a large amount of NaCl at low temperatures with short reaction times prefers metallic phases. The existence of the semiconducting phase in MoS2 lateral heterostructures significantly enhances the stability of the metallic phases through passivation of reactive edges. The same approach can be applied to other transition metal dichalcogenides (TMDs), such as WS2, leading to boosting of basic research and application of TMDs in metallic phases.
