This study presents a structuration approach to reach a high luminous transmittance () and solar modulation efficiency () of thermochromic vanadium dioxide () thin films. Before starting optical simulations, we confirm that the optical properties of monoclinic continuous films deposited by reactive magnetron sputtering show a good correspondence with numerical results. Then, calculations on ordered nanostripes demonstrate an enhanced transmittance due to the presence of vertical openings, leading to a variety of photonic effects. A series of optimizations by varying the column width, period, and film thickness establishes that 20 nm wide and 10 nm separated nanostripes have a of 14.2% and a of 47.6% for a film thickness of 250 nm. In comparison to a dense film without nanostructuring, the film transparency (related to ) is significantly enhanced, while remains unchanged. Furthermore, this also translates into a favorable, less opaque color, so the geometry could be useful for various thermochromic applications, such as smart windows.
