Dilute nitrides lattice-matched to GaP were studied to explore the possibilities to improve their properties by additional indium or arsenic content in the GaPN alloy for further utilization in solar cells. Admittance spectroscopy shows that intrinsic layers of GaPNAs and InP/GaPN grown by molecular-beam epitaxy have unintentional background silicon donor doping. Deep-level transient spectroscopy allowed us to reveal several defect levels. In GaPNAs, two defect levels were detected at Ec − 0.58 eV and Ev + 0.44 eV, with respective concentrations of 4 × 1015 cm−3 and 2 × 1015 cm−3. After thermal annealing, these could be reduced by a factor of two and by more than one order of magnitude, respectively, leading to an increase of external quantum efficiency and open-circuit voltage of solar cells. The InP/GaPN layer exhibits a defect level at Ec − 0.44 eV (with a concentration of 2 × 1014 cm−3), which is of similar nature as the one at Ec − 0.58 eV in GaPNAs. Furthermore, unlike in GaPNAs, defect levels close to midgap were also detected in the InP/GaPN layer. These non-radiative recombination centers lead to poorer photoelectric properties of solar cells based on InP/GaPN as compared to those based on GaPNAs. Therefore, the introduction of arsenic in the compound and post-growth thermal annealing allowed us to reduce the defect concentrations in dilute nitrides and improve photoelectrical properties for photovoltaic applications.
Skip Nav Destination
Article navigation
14 July 2020
Research Article|
July 14 2020
Defect properties of solar cells with layers of GaP based dilute nitrides grown by molecular beam epitaxy
Special Collection:
Defects in Semiconductors 2020
Artem I. Baranov
;
Artem I. Baranov
a)
1
Saint Petersburg National Research Academic University RAS
, 194021 Saint Petersburg, Russia
2
Saint Petersburg Electrotechnical University
, 197376 Saint Petersburg, Russia
3
Université Paris-Saclay, CentraleSupélec, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 91192 Gif-sur-Yvette, France
4
Sorbonne Université, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 75252 Paris, France
a)Author to whom correspondence should be addressed: [email protected]
Search for other works by this author on:
Alexander S. Gudovskikh
;
Alexander S. Gudovskikh
1
Saint Petersburg National Research Academic University RAS
, 194021 Saint Petersburg, Russia
2
Saint Petersburg Electrotechnical University
, 197376 Saint Petersburg, Russia
Search for other works by this author on:
Anton Yu. Egorov
;
Anton Yu. Egorov
1
Saint Petersburg National Research Academic University RAS
, 194021 Saint Petersburg, Russia
Search for other works by this author on:
Dmitry A. Kudryashov
;
Dmitry A. Kudryashov
1
Saint Petersburg National Research Academic University RAS
, 194021 Saint Petersburg, Russia
Search for other works by this author on:
Sylvain Le Gall
;
Sylvain Le Gall
3
Université Paris-Saclay, CentraleSupélec, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 91192 Gif-sur-Yvette, France
4
Sorbonne Université, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 75252 Paris, France
Search for other works by this author on:
Jean-Paul Kleider
Jean-Paul Kleider
3
Université Paris-Saclay, CentraleSupélec, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 91192 Gif-sur-Yvette, France
4
Sorbonne Université, CNRS, Laboratoire de Génie Electrique et Electronique de Paris
, 75252 Paris, France
Search for other works by this author on:
a)Author to whom correspondence should be addressed: [email protected]
Note: This paper is part of the Special Topic on Defects in Semiconductors 2020.
J. Appl. Phys. 128, 023105 (2020)
Article history
Received:
October 31 2019
Accepted:
June 26 2020
Citation
Artem I. Baranov, Alexander S. Gudovskikh, Anton Yu. Egorov, Dmitry A. Kudryashov, Sylvain Le Gall, Jean-Paul Kleider; Defect properties of solar cells with layers of GaP based dilute nitrides grown by molecular beam epitaxy. J. Appl. Phys. 14 July 2020; 128 (2): 023105. https://doi.org/10.1063/1.5134681
