Defect-mediated metastability and carrier lifetimes in polycrystalline (Ag,Cu)(In,Ga)Se₂ absorber materials Available to Purchase

Using a combination of optical and electrical measurements, we develop a model for metastable defects in Ag-alloyed Cu(In,Ga)Se₂, one of the leading thin film photovoltaic materials. By controlling the pre-selenization conditions of the back contact prior to the growth of polycrystalline (Ag,Cu)(In,Ga)Se₂ absorbers and subsequently exposing them to various stresses (light soaking and dark-heat), we explore the nature and role of metastable defects on the electro-optical and photovoltaic performance of high-efficiency solar cell materials and devices. Positron annihilation spectroscopy indicates that dark-heat exposure results in an increase in the concentration of the selenium–copper divacancy complex (V_Se–V_Cu), attributed to depassivation of donor defects. Deep-level optical spectroscopy finds a corresponding increase of a defect at E_v + 0.98 eV, and deep-level transient spectroscopy suggests that this increase is accompanied by a decrease in the concentration of mid-bandgap recombination centers. Time-resolved photoluminescence excitation spectroscopy data are consistent with the presence of the V_Se–V_Cu divacancy complex, which may act as a shallow trap for the minority carriers. Light-soaking experiments are consistent with the V_Se–V_Cu optical cycle proposed by Lany and Zunger, resulting in the conversion of shallow traps into recombination states that limit the effective minority carrier recombination time (and the associated carrier diffusion length) and an increase in the doping density that limits carrier extraction in photovoltaic devices.
