Bulk n-type β-Ga2O3 samples with orientation (−201) and (010) were exposed to a high density hydrogen plasma at 330 °C for 0.5 h. The effects were radically different for the two orientations. For the (−201) sample, H plasma exposure increased the net surface concentration of shallow donors from 2.7 × 1017 cm−3 to 2.6 × 1018 cm−3, with the shallow donors having an ionization energy close to 20 meV as deduced from the temperature dependence of the series resistance of Ni Schottky diodes. By sharp contrast, H plasma exposure of the (010) sample led to a strong decrease in the net shallow donor density from 3.2 × 1017 cm−3 to below 1015 cm−3 in the top 0.9 μm of the sample and to 3.2 × 1016 cm−3 near the edge of the space charge region at 0 V, with the total width of the region affected by plasma treatment being close to 1.1 μm. For both orientations, we observed a major decrease in the concentration of the dominant E2 traps near Ec-0.82 eV related to Fe acceptors. The deep trap spectra in hydrogenated samples were dominated by the E2* traps commonly ascribed to native defects in β-Ga2O3. The peak of these traps with a level near Ec-0.74 eV was masked in the starting samples by the peak of the E2 Fe acceptors present in high concentration, so that E2* only broadened the Fe peak on the low temperature side, but could be revealed by the modeling of the spectra. The concentration of the E2* center was not strongly affected in the hydrogen-treated samples with orientation (010), but in the (−201) samples, the concentration of the E2* peak was greatly enhanced. The results are discussed in conjunction with previous reports on hydrogen plasma treatment of β-Ga2O3 and on obtaining p-type conductivity in the surface layers of β-Ga2O3 crystals annealed in molecular hydrogen at high temperatures [Islam et al., Sci. Rep. 10, 6134 (2020)].
Skip Nav Destination
,
,
,
,
,
,
,
,
CHORUS
Article navigation
7 May 2020
Research Article|
May 01 2020
Anisotropy of hydrogen plasma effects in bulk n-type β-Ga2O3 Available to Purchase
A. Y. Polyakov;
A. Y. Polyakov
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
In-Hwan Lee
;
In-Hwan Lee
2
Department of Materials Science and Engineering, Korea University
, Anamro 145, Seoul 02841, South Korea
Search for other works by this author on:
Andrew Miakonkikh
;
Andrew Miakonkikh
3
Valiev Institute of Physics and Technology, Russian Academy of Sciences
, Moscow, 117218, Nahimovsky Ave, 36(1), Moscow, Russia
Search for other works by this author on:
A. V. Chernykh
;
A. V. Chernykh
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
N. B. Smirnov
;
N. B. Smirnov
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
I. V. Shchemerov;
I. V. Shchemerov
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
A. I. Kochkova;
A. I. Kochkova
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
A. A. Vasilev;
A. A. Vasilev
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
Search for other works by this author on:
S. J. Pearton
S. J. Pearton
a)
4
Department of Materials Science and Engineering, University of Florida
, Gainesville, Florida 32611, USA
a)Author to whom correspondence should be addressed: [email protected]
Search for other works by this author on:
A. Y. Polyakov
1
In-Hwan Lee
2
Andrew Miakonkikh
3
A. V. Chernykh
1
N. B. Smirnov
1
I. V. Shchemerov
1
A. I. Kochkova
1
A. A. Vasilev
1
S. J. Pearton
4,a)
1Semiconductor Electronics and Physics of Semiconductors,
National University of Science and Technology MISiS, Moscow
, Leninsky pr. 4, Moscow 119049, Russia
2
Department of Materials Science and Engineering, Korea University
, Anamro 145, Seoul 02841, South Korea
3
Valiev Institute of Physics and Technology, Russian Academy of Sciences
, Moscow, 117218, Nahimovsky Ave, 36(1), Moscow, Russia
4
Department of Materials Science and Engineering, University of Florida
, Gainesville, Florida 32611, USA
a)Author to whom correspondence should be addressed: [email protected]
J. Appl. Phys. 127, 175702 (2020)
Article history
Received:
January 16 2020
Accepted:
April 15 2020
Citation
A. Y. Polyakov, In-Hwan Lee, Andrew Miakonkikh, A. V. Chernykh, N. B. Smirnov, I. V. Shchemerov, A. I. Kochkova, A. A. Vasilev, S. J. Pearton; Anisotropy of hydrogen plasma effects in bulk n-type β-Ga2O3. J. Appl. Phys. 7 May 2020; 127 (17): 175702. https://doi.org/10.1063/1.5145277
