Near-junction heat spreaders for hot spot thermal management of high power density electronic devices Available to Purchase

Many high power (opto-) electronic devices such as transistors, diodes, and lasers suffer from significant hot spot temperature rises due to the high heat fluxes generated in their active area, which limits their performance, reliability, and lifetime. Employing high thermal conductivity materials near the heat source, known as near-junction heat spreaders, offers a low-cost and effective thermal management approach. Here, we present analytical heat spreader models and a methodology to evaluate their performance. Experimental demonstration of near-junction diamond heat spreaders on vertical GaN PiN diodes revealed significantly reduced spreading resistances, along with very low temperature gradients across the device. The findings in this work provide design guidelines and demonstrate excellent prospects, especially for the devices on low thermal conductivity substrates. The theoretical analysis of optimized diamond heat spreaders shows an 86% reduction of spreading resistance for GaN devices and 98% for Ga₂O₃ devices. In addition, our results show that a 3 μm-thick layer of high-quality CVD-deposited diamond heat spreaders on GaN-on-Si devices can provide better heat spreading than GaN-on-SiC devices and perform similar to GaN-on-diamond devices, highlighting the significant potential of heat spreaders as an effective and low-cost thermal management approach.
