Upon light irradiation, photochromic materials exhibit drastic changes in absorbance in addition to molecular and mechanical changes. In this study, we demonstrated optical trapping of photochromic microcrystals in a double fiber optical tweezers system combined with two external lights for photoisomerization and observed changes in the trapping force by photoisomerization. In situ photoisomerizations of the single crystal trapped in the system were performed thrice revealing a reversible change in the trapping force. The trapping stiffness for the colored crystal was one-third of that for the decolorized crystal in the axial direction, whereas almost no difference was observed in the transverse direction. Furthermore, based on the intermittent motion and asymmetry of the positional distribution of the trapped crystals, we inferred that the motion includes transitions through multiple stable sites, and the ease of the transition is related to the isomerization state of the crystals. Such switching of optical trapping indicates the possibility of revealing the physical properties of trapped materials through trapping schemes, and the nonlinearity in the trapping is also expected to be applied to advanced computing with physical phenomena.
Skip Nav Destination
,
,
,
,
,
Article navigation
12 September 2022
Research Article|
September 15 2022
Optical trapping of photochromic microcrystals by a dual fiber tweezers Available to Purchase
K. Uchiyama
;
K. Uchiyama
a)
(Conceptualization, Data curation, Methodology, Project administration, Resources, Software, Validation, Visualization, Writing – original draft, Writing – review & editing)
1
University of Yamanashi
, 4-3-11 Takeda, Kofu, Yamanashi 400-8511, Japan
a)Author to whom correspondence should be addressed: [email protected]
Search for other works by this author on:
J. Fick
;
J. Fick
(Methodology, Project administration, Software, Visualization, Writing – original draft, Writing – review & editing)
2
Université Grenoble Alpes, CNRS, Institut Néel
, 38000 Grenoble, France
Search for other works by this author on:
S. Huant;
S. Huant
(Conceptualization, Data curation, Project administration, Supervision, Writing – original draft, Writing – review & editing)
2
Université Grenoble Alpes, CNRS, Institut Néel
, 38000 Grenoble, France
Search for other works by this author on:
K. Uchida
;
K. Uchida
(Methodology, Resources, Writing – original draft, Writing – review & editing)
3
Ryukoku University
, 1-5 Yokotani, Oe-cho, Seta, Otsu, Shiga 520-2194, Japan
Search for other works by this author on:
M. Naruse
;
M. Naruse
(Project administration, Supervision, Writing – original draft, Writing – review & editing)
4
Department of Information Physics and Computing, Graduate School of Information Science and Technology, The University of Tokyo
, 7-3-1 Bunkyo-ku, Tokyo 113-8656, Japan
Search for other works by this author on:
H. Hori
H. Hori
(Conceptualization, Data curation, Project administration, Writing – original draft, Writing – review & editing)
1
University of Yamanashi
, 4-3-11 Takeda, Kofu, Yamanashi 400-8511, Japan
Search for other works by this author on:
K. Uchiyama
1,a)
J. Fick
2
S. Huant
2
K. Uchida
3
M. Naruse
4
H. Hori
1
1
University of Yamanashi
, 4-3-11 Takeda, Kofu, Yamanashi 400-8511, Japan
2
Université Grenoble Alpes, CNRS, Institut Néel
, 38000 Grenoble, France
3
Ryukoku University
, 1-5 Yokotani, Oe-cho, Seta, Otsu, Shiga 520-2194, Japan
4
Department of Information Physics and Computing, Graduate School of Information Science and Technology, The University of Tokyo
, 7-3-1 Bunkyo-ku, Tokyo 113-8656, Japan
a)Author to whom correspondence should be addressed: [email protected]
Appl. Phys. Lett. 121, 111103 (2022)
Article history
Received:
June 01 2022
Accepted:
August 26 2022
Citation
K. Uchiyama, J. Fick, S. Huant, K. Uchida, M. Naruse, H. Hori; Optical trapping of photochromic microcrystals by a dual fiber tweezers. Appl. Phys. Lett. 12 September 2022; 121 (11): 111103. https://doi.org/10.1063/5.0101484
