The purpose of this article is introduction to experimental research of steam turbine control valve executed in Doosan Škoda Power (DSPW). First part describes air test rig, model, location of probes and measurement instrumentation. Second part describes measured data in time domain. There was done frequency analysis of signal obtained from pressure KULITE probe e.g. fast Fourier transform, power spectral density estimation, etc. There are shown results obtained also from other probes in this article. The main aim of this research is reveal nonstationarities, which can appear in turbine control valve during operation especially during part-load.

1.
TAJČ
,
L.
;
BEDNÁŘ
,
L.
,
Makarov
A.
, Regulační ventily s tvarovaným kanálem a podpíchnutou kuželkou – Škoda Energo,
Plzeň
,
2001
2.
Li-Fei
Zeng
;
Guan-Wei
Liu
,
Jing-Ru
Mao
,
Shun-Sen
Wang
,
QI
Yuan
,
HAO
Yuan
,
Kai-Ge
Wang
,
Jun-Jie
Zhang
,
Ya-Tao
Xu
, Flow-induced vibration and noise in control valve –, Mechanical Engineering Science,
Institute of Turbomachinery, Xi’an Jiaotong University, Xi’an
,
PR China
, Shenhua Guohua (Beijing) Electric Power Research Institute Co. Ltd,
2015
3.
Kollross
,
P.
,
Introduction to flow instability in turbine control valve
,
AIP Conference proceeding - 36th meeting of departments of fluid mechanics and thermodynamics
,
Pilsen
,
2017
4.
Luxa
,
M.
,
Šimurda
,
D.
,
Interní zpráva akademie věd pro DSPW
,
Nový Knín
,
2017
