Finite element analysis of cooling mechanism by flat heat-sinks in ultra-high CPV systems Free

The potential cost reduction of Concentrator photovoltaic (CPV) systems is closely related to the concentration factor because higher light concentrations imply lower amount of semiconductor material required for the solar cells. However, the thermal management at such ultra-high light fluxes is difficult. The use of small-sized solar cells is beneficial for improving the thermal management. Among the possible cooling strategies, the use of flat-plate heat-sinks for passive cooling, if feasible, would be the simplest way to dissipate heat and would accelerate the development of ultra-high CPV prototypes. In this work, a thermal 3D finite-element model is used to investigate the possibilities of flat-plate heat-sinks for passive cooling at concentration ratios within 2,000-10,000 suns. Results show that a micro solar cells of 1mm x 1mm area can be thermally handled with conventional Aluminium flat plate heat-sinks up to 10,000 suns.
