Effect of tank geometry on its average performance Available to Purchase

The mathematical model of non-stationary filling of vertical submerged tanks with gaseous uranium hexafluoride is presented in the paper. There are calculations of the average productivity, heat exchange area, and filling time of various volumes tanks with smooth inner walls depending on their “height : radius” ratio as well as the average productivity, degree, and filling time of horizontal ribbing tank with volume 6·10⁻² m³ with change central hole diameter of the ribs. It has been shown that the growth of “height / radius” ratio in tanks with smooth inner walls up to the limiting values allows significantly increasing tank average productivity and reducing its filling time. Growth of H/R ratio of tank with volume 1.0 m³ to the limiting values (in comparison with the standard tank having H/R equal 3.49) augments tank productivity by 23.5 % and the heat exchange area by 20%. Besides, we have demonstrated that maximum average productivity and a minimum filling time are reached for the tank with volume 6·10⁻² m³ having central hole diameter of horizontal ribs 6.4·10⁻² m.
